OSFP-400G-DR4 HP 400Gbps 400GBase-DR4 Transceiver Module
OSFP-400G-DR4 Overview
The HP OSFP-400G-DR4 is a 400 Gigabit Ethernet OSFP optical transceiver designed for high-speed, short-reach single-mode fiber connections. It supports the 400GBase-DR4 standard, delivering a total data rate of 400 Gbps via four parallel lanes, each running at 100 Gbps using PAM4 modulation. Operating at a 1310 nm wavelength, it uses a 12-fiber MTP/MPO connector with 8 active fibers (4 transmit, 4 receive) for efficient parallel data transmission. The module supports distances of up to 500 meters over single-mode fiber, making it suitable for data center interconnects, high-performance computing, and short campus backbone links. It is hot-swappable, compliant with OSFP MSA and IEEE 802.3bs 400G Ethernet standards, ensuring broad interoperability.
OSFP-400G-DR4 Technical Specifications
HP 400Gbps 400GBase-DR4 Single-mode Fibre 500m 1310nm MTP/MPO Connector OSFP Transceiver Module
Manufacturer Part Number: OSFP-400G-DR4
Brand Name: HP
Product Type: OSFP Transceiver Module
Data Rate: 400Gbps
Form Factor: OSFP (Octal Small Form-Factor Pluggable)
Transceiver Type: 400GBase-DR4
Media Type Supported: Single-Mode Fiber (SMF)
Connector Type: MTP/MPO-12 APC
Wavelength: 1310nm
Maximum Reach: Up to 500m over SMF
Transmission Mode: 4 parallel lanes (100G per lane)
Ethernet Standard: IEEE 802.3bs 400G Ethernet
Compatibility: HP switches and OSFP-compliant ports
Hot Swappable: Yes
Digital Diagnostics: DDM/DOM supported
Power Consumption: ~12W (typical)
Operating Temperature: 0°C to 70°C
Application: High-speed data center interconnects
Compliance Standards: OSFP MSA, RoHS
Dimensions: Standard OSFP size
Weight: Lightweight design
